Pessoa de Contato : Peter Sun
Número de telefone : 0086-13823381460

CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment

  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
Lugar de origem Cantão, China
Marca MYSUN
Número do modelo CQC20011252316
Quantidade de ordem mínima 3050

Contacte-me para amostras grátis e vales.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Se você tem algum interesse, nós fornecemos a ajuda online de 24 horas.

x
Detalhes do produto
Material condutor Cobre enlatado Diâmetro 0,051 mm2, 0,08 mm2, 0,13 mm2, 0,21 mm2, 0,32 mm2, 0,40 mm2, 0,52 mm2, 0,75 mm2, 0,82 mm2, 1,00 mm2,
Material de isolamento FEP Tensão nominal 600V
Tipo de condutor Sólido Forma Redondo
Classificação de temperatura 150°C, 200°C, 200°C Tipo Isolado
Comprimento da unidade 305/1000 Resistência máxima ao condutor 381, 239, 150, 94,2, 59,4, 46,6, 37,4, 24,8, 23,5, 18,7, 14,7, 12,5, 9,22, 7,47, 5,75, 4,68, 3,62, 3
Espessura nominal 0.510mm Diâmetro de isolamento 1,32 mm, 1,40 mm, 1,50 mm, 1,62 mm, 1,80 mm, 1,90 mm, 2,00 mm, 2,15 mm, 2,20 mm, 2,40 mm, 2,60 mm, 2
Diâmetro do condutor 0,30 mm, 0,38 mm, 0,48 mm, 0,60 mm, 0,78 mm, 0,85 mm, 0,96 mm, 1,12 mm, 1,17 mm, 1,35 mm, 1,52 mm, 1 Construção 7/0,10, 7/0,127, 7/0,16, 19/0,12, 19/0,15, 19/0,17, 19/0,19, 19/0,225, 19/0,235, 19/0,26, 19/0,30, 1
Tamanho awg 0,051, 0,08, 0,13, 0,21, 0,32, 0,40, 0,52, 0,75, 0,82, 1,00, 1,31, 1,50, 2,08, 2,50, 3,31, 4,00, 5,2
Destacar

GB/T38296-2019 Standard FEP Wire

,

UAV Motor Generator FEP Wire

,

Medical Equipment FEP Wire
Deixe um recado
Descrição de produto
CQC FEP Wire 600V 200°C Tinned Nickel Plated Copper High Temperature E-200/TX/FEP Wire for UAV Motor Generator
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 0 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 0
Specification
CQC V048486 CQC20011252316 E-200/TX/FEP UL1330 Conductor Insulation Max. Cond Resistance (Ω/KM) Unit length (M)(Ft)
Size (AWG) Construction (No.mm) Diameter (mm) Nominal thickness (mm) Diameter (mm)
0.051 7/0.10 0.30 0.510 1.32 381 610/2000
Click Contact us Get the Best Quote
Company Profile
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 2 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 2 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 4 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 4
Our Products
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 6 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 6
Application
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 8 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 8
Our Overseas Clients
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 10 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 10
Exhibition
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 12 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 12
Certifications
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 14 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 14
FAQ
1. Who Are We?
We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
2. What Can We Provide?
We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
3. Why Choose Us?
  • Free Sample
  • Competitive Price
  • High Quality Standard
  • Customized Service
4. What Certifications Do We Have?
We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
5. What Services Can We Provide?
Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
