UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications

  • UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications
  • UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications
  • UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications
  • UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications
  • UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications
  • UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications
Lugar de origem Cantão, China
Marca MYSUN
Número do modelo UL8207
Quantidade de ordem mínima 3050

Contacte-me para amostras grátis e vales.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Se você tem algum interesse, nós fornecemos a ajuda online de 24 horas.

x
Detalhes do produto
Material condutor Cobre enlatado Diâmetro 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 26AWG
Material de isolamento Borracha Tensão nominal 300 v
Tipo de condutor Sólido Forma Redondo
Classificação de temperatura 180°C Tipo Isolado
Cor Todas as cores Comprimento da unidade 305/1000
Tensão 300V Isolamento FEP
Condutor Cobre Estanhado/Cobre Prateado Resistência máxima ao condutor 150 Ω/KM (26AWG), 94,2 Ω/KM (24AWG), 59,4 Ω/KM (22AWG), 36,7 Ω/KM (20AWG), 23,2 Ω/KM (18AWG), 20 Ω/K
Espessura nominal 0,305 mm (26AWG-17AWG), 0,350 mm (16AWG-14AWG), 0,450 mm (11AWG)
Destacar

300V FEP Wire

,

180C UL8207 Wire

,

Sensor Application Sensing Wire
Deixe um recado
Descrição de produto
UL8207 FEP Wire - High Temperature Heat Resistant Wire for Sensors
Supplies Fortune 500 Companies - Top FEP Wire Supplier In China
UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 0 UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 1
Product Specifications
UL8207 Conductor Insulation Max. Cond Resistance (Ω/KM) Unit length (M)(Ft)
26 7/0.16 0.305 150 610/2000
24 7/0.20 0.305 94.2 610/2000
22 19/0.15 0.305 59.4 305/1000
20 19/0.19 0.305 36.7 305/1000
18 19/0.23 0.305 23.2 305/1000
17 19/0.26 0.305 20 305/1000
16 19/0.30 0.350 14.6 305/1000
15 19/0.32 0.350 13.7 305/1000
14 19/0.37 0.350 8.96 305/1000
13 19/0.41 0.350 7.16 305/1000
12 19/0.47 0.350 5.64 305/1000
11 19/0.52 0.450 4.70 305/1000
10 19/0.43 0.350 3.55 305/1000
Click Contact us Get the Best Quote
Company Profile
UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 2 UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 3
Our Products
UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 4
Applications
UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 5
Our Overseas Clients
UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 6
Exhibitions
UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 7
Certifications
UL8207 FEP Wire 300V 180C High Temperature Heat Resistant Sensing Wire for Sensor Applications 8
Frequently Asked Questions
  • Who Are We? We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, with production bases in Dongguan and Jingzhou.
  • What Can We Provide? High-temperature wires and cables, silicone tubing including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, and wiring harnesses.
  • Why Choose Us? Free samples, competitive pricing, high quality standards, and customized services.
  • What Certifications Do We Have? UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC certification.
  • What Services Can We Provide? Accepted delivery terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted payment currency: USD, EUR, CNY. Accepted payment type: T/T, L/C, PayPal, Western Union, Cash.
